| Overall Size(W*D*H) | 770*680*565(mm)(included foot 665mmH) |
| Inner Size(W*D*H) | 540*510*125(mm) |
| Range of Temperature | 0-400℃ |
| Upper Tube Range of Temperature | 0-400℃ |
| Down Tube Range of Temperature | 0-400℃ |
| Rated Power | 7.8 KW |
| Rated Electric Current | 16.4 A |
| Rated Voltage | 380 V±10% |
| Net weight | 125 kg |
| Warranty | One year |
| Suitable for | Cafe, bar shop, bakery store, dessert shop |
| Applied to | Pizza,muffin,cake,bread |
| TYPE | VOLTAGE | PHASE | FREQUENCY | RATED HEAT INPUT | AMPERAGE | SUPPLY | BREAKERS | |||
| L1 | L2 | L3 | N | |||||||
| DO-2 | 380V | 3 | 50/60 Hz | 7.8kW | 9.1 | 16.4 | 9.1 | 9.1-16.4 | 4 pole 5 wire (3L+N+ G) |
As per local code |
