| Overall size(W*D*H) | 1145*1050*770(mm) |
| Inner size(W*D*H) | 710*710*145(mm) |
| Range of temperature | 0-400℃ |
| Upper tube range of temperature | 0-400℃ |
| Down tube range of temperature | 0-400℃ |
| Rated Power | 10.8KW |
| Rated electric current | 17A(each layer) |
| Rated voltage | 380V/50Hz |
| Net weight | 240kg |
| Warranty | One year |
| Suitable for | bakery store, dessert shop, Medium and large pizza shop |
| Application | Pizza,muffin,cake,bread |
| TYPE | VOLTAGE | PHASE | Hertz | RATED HEAT INPUT | AMPERAGE | SUPPLY | BREAKERS | |||
| L1 | L2 | L3 | N | |||||||
| DO-2L | 220V | 3 | 50/60 Hz | 10.8kW | 28.3 | 28.3 | 28.3 | – | 3 pole 4 wire (3L+ G) |
As per local code |
| 208V | 3 | 50/60 Hz | 30.0 | 30.0 | 30.0 | – | 3 pole 4 wire (3L+ G) |
As per local code | ||
| 380V | 3 | 50/60 Hz | 16.4 | 16.4 | 16.4 | 8.2-16.4 | 4 pole 5 wire (3L+N+ G) |
As per local code | ||
